VCW Series

Features

MOTOR GUARD

• PROTECTS MOTOR / BRAKE
• BENT AND WELDED STEEL PLATE
• KEEPS TAIL END OF ROPE OFF DECK
• EASILY REMOVABLE

SEALED MOTOR / BRAKE

• TENV MARINE DUTY IP66 RATED
• EPOXY DIPPED WINDINGS
• NO BRAKE ADJUSTMENT REQUIRED

DIRECT DRIVE

• GEARBOX DIRECTLY COUPLED TO HEAD
• FULLY ENCLOSED HELICAL BEVEL REDUCER
• NO EXTERNAL GEARING / WEAR ISSUES
• PRECISION MACHINED COUPLING SHAFT

CAPSTAN HEAD

• PRECISION MACHINED STEEL
• SMOOTH CORE TO EXTEND ROPE LIFE
• PROFILE BASED ON ASTM STANDARD
• HOLES FOR DOGGING PEGS (OPTIONAL)

EXTERNAL BEARING

• SEALED / MAINTENANCE FREE
• REDUCES LOAD ON GEARBOX
• PROVIDES HIGH BOLLARD CAPACITY

FABRICATED BASE

• FULLY WELDED STEEL FRAME
• COMPLETELY HOUSES GEARBOX
• BOLT PATTERN PROVIDED
• INTEGRAL LIFTING LUGS
